OpenGate MQTT connector

Quick OpenGate MQTT guide

Last updated on 5 min read

This post shows how to use the OpenGate MQTT connector.

The MQTT protocol provides a lightweight method of carrying out messaging using a publish/subscribe model. These features make it suitable for Internet of Things messaging, such as with low-power sensors or mobile devices such as phones, embedded computers, or microcontrollers.

In MQTT, there are a few basic concepts that you need to understand:

  • Publish/Subscribe - In a publish and subscribe system, a device can publish a message on a topic or be subscribed to a particular topic to receive messages.
  • Messages - Messages are the information you want to exchange between your devices. These messages can either be a command or data.
  • Topics - Topics are the way you register interest in incoming messages or how you specify where you want to publish the message.
  • Broker - The broker is primarily responsible for receiving all messages, filtering them, deciding who is interested in them, and then publishing the message to all subscribed clients.

In MQTT, a publisher (device/client) publishes messages on a topic, and a subscriber must subscribe to that topic to view the message.

OpenGate MQTT connector

These are the connection data:

  • Host: api.opengate.es
  • Port: 1883
  • User: device_id
  • Password: your_api_key

How to obtain your API key

In addition, you’ll need your API key. Once you login onto the OpenGate web interface, you can find your API key by clicking on the cogs at the top-right of the OpenGate home page, then on the User option, and finally on the “Click to show” link.

OpenGate Topics

  • To publish collected data: odm/iot/{device_id}
  • To subscribe to incoming operations from OpenGate: odm/request/{device_id}
  • To publish operation responses: odm/response/{device_id}
  • To ask OpenGate for pending operations: odm/operationOnDemand/{device_id}

You have to replace {device_id} with the OpenGate unique identifier of your device.

Payload

The payload definition in the official OpenGate documentation to publish data is entirely valid. You only have to add a "device": "device_id" field, filled with your OpenGate device unique identifier, at the top level of the JSON document with the collected values. See the following example:

{
  "version": "1.0.0",
  "device": "device_id",
  "datastreams": [
    {
      "id": "temperature",
      "datapoints": [
        {
          "at": 1431602523123,
          "value": 24.1
        }
      ]
    }
  ]
}

Using mosquitto client

Eclipse Mosquitto is an open source (EPL/EDL licensed) message broker that implements the MQTT protocol versions 5.0, 3.1.1, and 3.1. Mosquitto is lightweight and suitable for all devices, from low-power single board computers to full servers.

Subscribing to OpenGate MQTT operations topic with mosquito client

Your device must subscribe to odm/request/{device_id} topic to receive operation requests from the north API. Replace {device_id} with the provisioned device id:

// extract from provision JSON
...
"provision.device.identifier": {
        "_value": {
            "_current": {
                "value": "sensehat01"
            }
        }
    }
...

Example using mosquitto_sub:

# Debian/Ubuntu install: sudo apt-get install mosquitto-clients
mosquitto_sub \
  -h api.opengate.es \
  -u "your-device-id" \
  -P "your-api-key" \
  -t "odm/request/your-device-id"

Launch operations using the North API

The North API end-point for jobs and operations is https://api.opengate.es:443/north/v80/operation/jobs.

Every http request to the North or South API must include this header: X-ApiKey: your-api-key.

Example using curl:

curl -X POST \
    -H "Content-Type: application/json" \
    -H "X-ApiKey: your-api-key" \
    -d @SET_DEVICE_PARAMETERS.json \
    https://api.opengate.es:443/north/v80/operation/jobs

SET_DEVICE_PARAMETERS.json file used in the previous example:

{
  "job": {
    "request": {
      "operationParameters": {
        "timeout": 90000,
        "retries": 0,
        "retriesDelay": 0
      },
      "name": "SET_DEVICE_PARAMETERS",
      "schedule": {
        "stop": {
          "delayed": 120000
        }
      },
      "parameters": {
        "variableList": [{ "name": "f", "value": "180" }]
      },
      "target": {
        "append": {
          "entities": ["sensehat01"]
        }
      },
      "active": true
    }
  }
}

HTTP response:

{
  "id": "0898f8e6-6773-43d4-ac34-fab214581463",
  "request": {
    "name": "SET_DEVICE_PARAMETERS",
    "parameters": {
      "variableList": [
        {
          "name": "r",
          "value": "180"
        }
      ]
    },
    "active": true,
    "notify": false,
    "user": "sensehat@amplia.es",
    "schedule": {
      "stop": {
        "delayed": "120000"
      },
      "scattering": {
        "strategy": {}
      },
      "window": {
        "weekly": [
          {
            "daily": {}
          }
        ]
      }
    },
    "operationParameters": {
      "timeout": 90000,
      "retries": 0,
      "retriesDelay": 0
    }
  },
  "report": {
    "execution": {},
    "target": {}
  }
}

If you didn’t provision the parameter to be set in a data stream, you’ll receive the following response from the North API:

{
  "errors": [
    {
      "code": "0x020003",
      "message": "At least one valid reference to an entity (list of entities or tags) is required."
    }
  ]
}

Processing operations on the device side

OpenGate operation routing

OpenGate routes operations to specific connectors depending on:

  • specific manufacturer and model pair
  • or specific operations.

For the sake of this example, let’s assume routing by manufacturer and model; thus, the provisioning must be (OpenGate/OpenGateMqtt):

...
"provision.device.model": {
        "_value": {
            "_current": {
                "value": {
                    "name": "OpenGateMqtt",
                    "manufacturer": "OpenGate"
                }
            }
        }
    }
...

Example operation: SET_DEVICE_PARAMETERS

Parameters to be set must be configured in a data model as data streams and must be WRITABLE (and only WRITABLE).

Publishing operation responses to OpenGate MQTT connector with mosquito client

OpenGate only supports one MQTT session at the same time. Don’t connect two mosquitto_pub or mosquitto_sub clients simultaneously.

The following example publishes a JSON payload stored on SET_DEVICE_PARAMETERS_RESPONSE.json file with an example of the response required by OpenGate Operations Engine:

# Debian/Ubuntu install: sudo apt-get install mosquitto-clients
mosquitto_pub \
  -h api.opengate.es \
  -u "your-device-id" \
  -P "your-api-key" \
  -t "odm/response/your-device-id" \
  -f SET_DEVICE_PARAMETERS_RESPONSE.json

The following code is an example of a response SET_DEVICE_PARAMETERS_RESPONSE.json file:

{
  "version": "7.0",
  "operation": {
    "response": {
      "deviceId": "sensehat01",
      "timestamp": 1599810726318,
      "name": "SET_DEVICE_PARAMETERS",
      "id": "f5d56834-63b8-45d8-93cb-5fdfcc30de9b",
      "resultCode": "SUCCESSFUL",
      "resultDescription": "Success",
      "steps": [
        {
          "name": "SET_DEVICE_PARAMETERS",
          "timestamp": 1599810726318,
          "result": "SUCCESSFUL",
          "description": "Parameters set ok",
          "response": []
        }
      ]
    }
  }
}

Publishing IoT data

# Debian/Ubuntu install: sudo apt-get install mosquitto-clients
mosquitto_pub \
  -h api.opengate.es \
  -u "your-device-id" \
  -P "your-api-key" \
  -t "odm/iot/your-device-id" \
  -f iot_data.json

MQTT connector supports the payloads defined in the OpenGate’s public documentation, with the following extra considerations:

Additionally, the JSON message must include the field "device": "your-device-id". This field is required when you’re using the OpenGate MQTT connector.

{
  "version": "1.0.0",
  "device": "your-device-id",
  "datastreams": [
    {
      "id": "temperature.from.pressure",
      "datapoints": [
        {
          "at": 1529398727,
          "value": 28
        }
      ]
    },
    {
      "id": "temperature.from.humidity",
      "datapoints": [
        {
          "at": 1529398727,
          "value": 30
        }
      ]
    },
    {
      "id": "pressure",
      "datapoints": [
        {
          "at": 1529398727,
          "value": 957
        }
      ]
    },
    {
      "id": "humidity",
      "datapoints": [
        {
          "at": 1529398727,
          "value": 40
        }
      ]
    }
  ]
}
